200DL Underwater Housing for Panasonic Lumix G9 II Micro Four-Thirds Mirrorless Cameras

Description

A full featured and durable waterproof housing for Panasonic Lumix G9 II Micro Four-Thirds Mirrorless cameras, suitable for scuba, snorkel, surf, pool, and any application in or around the water.

Controls

Controls are provided for everything except Front dial, Rear Dial, Control Dial, Joystick, Diopter adjustment dial, AF-Point Scope / Fn2 button, and Preview / Fn3 button.

Strobe Connector

Ikelite Bulkhead with Manual Hotshoe.

Port Mount

DL (Dry Lock) system for a secure and watertight seal.

Note: A compatible lens port is required for waterproof operation and is sold separately. Choose the correct port components for the lens you will be using.

View the Port Chart here. (external link)

Specifications

Depth Rating60 meters (200 feet)Weight1.9 kg (4.2 lb)Dimensions22.6 x 18.5 x 16.5 cm (8.9 x 7.3 x 6.5 inches)

Pre-Dive Checks

Our signature open-groove design suspends the rear o-ring in a natural position for easier maintenance and reliability. It’s recommended to use a pump with a gauge to pull a vacuum on the housing to check for leaks before entering the water.

Construction

Ikelite’s specially formulated ABS-PC blend is highly durable yet significantly lighter than aluminum. The light color helps keep your camera cooler in warm, sunny environments.

Lens Support

Ikelite lens ports, known for being the lightest on the market, are robust and capable of standing up to rough surf. Zoom and focus gears vary depending on the lens used.

Wi-Fi Transfer

Utilize the camera’s built-in Wi-Fi feature to download photos to another device without removing the camera from the housing. This feature is only usable above water within close proximity to the connected device.

Compatibility

This housing does not accommodate the use of add-on grips, battery grips, eyepieces, LCD covers, or other accessories. Compatible exclusively with the Panasonic Lumix G9 II camera.

In the Box

• Housing with Rear O-ring #0132.59 and Front O-ring #0132.45 (installed)

• Zoom Gear Retainer #75900 (installed)

• Port Hole Cover #0200.92 (installed)

• Waterproof Bulkhead Cap #9104.7 (installed)

• Base with Left-Hand Quick Release Handle #4077.67 (installed)

• Tool for Zoom Gear Retainer #0945.06

• .050″ Hex Key #0945.11

• 1/16″ Hex Key #0945.16

• Silicone Lubricant 1cc tube
