Ikelite Underwater Housing Panasonic S5 II/S5 IIX

Ikelite 71315 200DL Panasonic S5 II/S5 IIX Housing

Product Details

About this Product

This Underwater Housing combined with the Sony ZV-E1 is a powerful combination for underwater videographers. The compact form factor makes it perfect for scuba diving, freediving, surf, pool, or any adventure.

The ZV-E1 features a 12 megapixel full frame CMOS sensor capable of UHD 4K video at up to 60p with no crop. 5-axis in-body image stabilization and a dedicated AI processing chip provide semi-professional performance in a truly travel-sized package.

Construction

The Ikelite specially formulated ABS-PC blend housing is highly durable, yet significantly lighter than aluminum. The light color keeps your camera cooler when shooting in warm, sunny environments.

Compatibility

Unless otherwise noted, this housing does not accommodate the use of add-on grips, battery grips, eyepieces, LCD covers, or other accessories.

Differences in lens and control placement prevent other camera models from being used in or adapted to this housing. Ikelite is not aware of any other models which may be used in or adapted to this housing.

We recommend adding the optional Vacuum Pump with Gauge # 47011 to pull a vacuum on the housing and check for leaks prior to entering the water.

LENS PORT REQUIRED (Sold Separately)

A compatible lens port is required for waterproof operation (sold separately). Choose the correct port components on the lens you will be shooting. View Port Chart

Specifications:

• 60m (200 ft) depth rating

• Controls are provided for everything except Rear Dial, Focus mode lever, Joystick Up/Down/Left/Right (Pressing ‘YES’ is supported), Preview (Fn2) button

• Strobe Connector: Ikelite Bulkhead with Manual Hotshoe

• Port Mount: DL (Dry Lock)

• Accessory Port:  M16 Thread

• Weight 2400 g (5.35 lb)

• Dimensions 229 x 184 x 152 mm (9 x 7.25 x 6″)

• 3″ diameter glass lens port

• 2 year limited warranty

In the Box

• Housing

• Rear o-ring # 0132.61

• Front o-ring # 0132.45

• Zoom Gear Retainer (installed)

• Port Hole Cover (installed)

• Waterproof Bulkhead Cap (installed)

• Base with Left-Hand Quick Release Handle (installed)

• Tool for Zoom Gear Retainer

• .050″ Hex Key1

• Silicone Lubricant 1cc Tube

Spare Parts

• Rear o-ring # 0132.61

• Front o-ring # 0132.45

• Port cover # 0200

• Silicone lubricant # 5020
